Fuel Lines for 1984 Mercedes-Benz 300D
No.
Part # / Description / Price
Price
5
Fuel Hose
Mercedes-Benz
Mercedes-Benz Description: From tank filter to feed line 200mm. Fuel line to fuel tank.
$22.50
$22.50
8
Spring Hose Clamp Mercedes-Benz
Mercedes-Benz Description: Between combination valve and breather pipe. Regeneration valve. Return hose to return line. From fuel tank to breather valve.
$4.00
$4.00
14
Hose Mercedes-Benz
Mercedes-Benz Notes: ORDER BY THE METER
Description: 160 mm. 13.3x3 mm. From fuel filter to feed line. 13.3x3 mm. 300 mm. 13.3x3 mm. 110mm. 13.3x3 mm. Order by the meter. 13.3x3 mm. 250 mm. 13.3x3 mm. From activated charcoal filter to regeneration valve. 13.3x3 mm. 100 mm from fuel return line to fuel tark. 13.3x3 mm.
$32.50
$32.50
17
Clamp Mercedes-Benz
Mercedes-Benz Description: FUEL HOSE TO RETURN LINEDiameter: 13mmMaterial thickness: 0,4mmWidth across flats: SW7. FROM FUEL FILTER TO FEED LINEDiameter: 13mmMaterial thickness: 0,4mmWidth across flats: SW7. FROM FUEL PUMP TO FILTERDiameter: 13mmMaterial thickness: 0,4mmWidth across ...
$6.75
$6.75
17
Clamp Mercedes-Benz
Mercedes-Benz Description: HOSE TO OIL TANK
Diameter: 13mm
Material thickness: 0,4mm
Width across flats: 7.
Diameter: 13mm
Material thickness: 0,4mm
Width across flats: 7.
29
Hose Clamp Mercedes-Benz
Mercedes-Benz Description: Cexpansion reservoir to activated charcoal filter 9- 13 mm. 9-13 mm. Fuel hose to filter 9- 13 mm. 9-13 mm. Return line 9- 13 mm. 9-13 mm. Fuel hose to fuel line. 9-13 mm. From activated charcoal filter to breather line. 9-13 mm. Oil connection hose. 9-13 mm.
$3.50
$3.50
128
Clamp Mercedes-Benz
Mercedes-Benz Description: Fuel line to floor,right. Fuel lines to vehicle floor. Brake line to cross member.
$1.20
$1.20
131
Clamp Mercedes-Benz
Mercedes-Benz Description: To firewall and longitudinal member. Fuel line to floor,right. Brake and fuel lines to vehicle floor.
$2.00
$2.00
140
Tensioner Mercedes-Benz
Mercedes-Benz Description: Underbody left. Fuel line to floor,right. To mount fuel lines. In wheelhouse front left. To firewall and longitudinal member. Brake line to cross member.
$5.00
$5.00
155
Damping Strip Mercedes-Benz
Mercedes-Benz Description: Fuel lines to cowl. Fuel lines to front partition panel. Fuel line to side member.
176
Tapping Screw Mercedes-Benz
Mercedes-Benz Description: Front fender to bumper bracket. Front fender partition panel to wheelhouse. Front fender to wheelhouse,bottom front. Bracket to frame. 6,3 x 13. Bracket to cowl. As required. 6.3x13. Bracket to wheel arch panel.
$1.70
$1.70
179
Clamp Mercedes-Benz
Mercedes-Benz Description: Feed line to fire wall. Fuel lines on floor under fuel tank. Breather line under rear floor. (vent line) from activated charcoal filter to boot. Brake and fuel lines to vehicle floor.
182
Damping Strip Mercedes-Benz
Mercedes-Benz Description: Fuel lines under steering. Brake line fastening. Regeneration line to frame. To mount fuel lines.
$1.90
$1.90
No.
Part # / Description / Price
Price
17
Hose Mercedes-Benz
Mercedes-Benz Notes: ORDER BY THE METER
Description: 160 mm. 13.3x3 mm. From fuel filter to feed line. 13.3x3 mm. 300 mm. 13.3x3 mm. 110mm. 13.3x3 mm. Order by the meter. 13.3x3 mm. 250 mm. 13.3x3 mm. From activated charcoal filter to regeneration valve. 13.3x3 mm. 100 mm from fuel return line to fuel tark. 13.3x3 mm.
$32.50
$32.50
