Rear Lid Latch-Type Lock, Rear Lid Attachment Parts for 1992 Mercedes-Benz 400E
No.
Part # / Description / Price
Price
14
Nut Holder
Mercedes-Benz
Mercedes-Benz Description: Lock to tail central part. At cross member below instrument panel. Tumbler to tail central part. Bracket to tail central part code 880 / 885. Interior part to c-pillar.
17
Lock Cylinder Mercedes-Benz
Mercedes-Benz Notes: STATE LOCK NUMBER WHEN ORDERING
Description: Less key code 885 used with infra-red closing system.
17
Lock Cylinder Mercedes-Benz
Mercedes-Benz Notes: COMFORT LOCKING MECHANISM ONLY USED WITH SPECIAL VERSION SLIDING/LIFTING ROOF, OR ELECTRIC WINDOW REGULATOR
STATE LOCK NUMBER WHEN ORDERING
STATE LOCK NUMBER WHEN ORDERING
Description: Less key. With comfort control.
17
Parts Kit, Lock Cylinder Mercedes-Benz
Mercedes-Benz Description: Only with code 466 (central locking mechanism). Workshop version,with key. Any lock.
$162.00
$162.00
17
Lock Cylinder Mercedes-Benz
Mercedes-Benz Notes: STATE LOCK NUMBER WHEN ORDERING
Description: Less key. Used with rear lid additional locking mechanism + code 885.
44
Seal Mercedes-Benz
Mercedes-Benz Description: Between lock and rear lid. Between lock and panelling. Between lock & tail central part.
65
Shim Plate Mercedes-Benz
Mercedes-Benz Description: Between lock upper part & rear lid. Lock upper part to rear lid. Burglary alarm system (edw).
66
Plate Mercedes-Benz
Mercedes-Benz Description: Locking clamp to rear lid. Lock upper part to rear lid. Burglary alarm system (edw).
71
Fastening Grommet Mercedes-Benz
Mercedes-Benz Description: Mercedes star to rear panel door. Badge on engine hood.
$4.20
$4.20
77
Pan Head Screw Mercedes-Benz
Mercedes-Benz Description: Front license plate. M 5x16. Handle ledge to rear lid m5x16. License plate lamp to rear lid m5x16. Rear license plate to rear body panel.
$2.40
$2.40
78
Rivet Nut Mercedes-Benz
Mercedes-Benz Description: Moulding type handle to rear panel door. Handle ledge to rear lid. License plate to rear lid.
$5.75
$5.75
86
$2.20
104
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Amplifier at c-pillar. Amplifier to bracket. Reinforcem. At bracket, left.
$3.50
$3.50
195
Screw Mercedes-Benz
Mercedes-Benz Description: M5X16
Diameter: 5mm
Strength / hardness class: 4.8
Thread code letter: M
Thread pitch: 1mm. License plate to rear lid. Fuel accumulator bracket to bracket. Engine control unit holder. Mirror at door, left. License plate to tail central part. Rearview mirror to door m5 x 16.
Diameter: 5mm
Strength / hardness class: 4.8
Thread code letter: M
Thread pitch: 1mm. License plate to rear lid. Fuel accumulator bracket to bracket. Engine control unit holder. Mirror at door, left. License plate to tail central part. Rearview mirror to door m5 x 16.
No.
Part # / Description / Price
Price
110
Rubber Bumper Mercedes-Benz
Mercedes-Benz Description: At trunk lid, bottom. Rear lid stiffening. For gap dimension. On rear lid. Tank attachment. To trunk lid below, side. Rear lid stop to rear body panel, bottom 14 mm. To lower trunk lid. At engine hood.
$4.20
$4.20
134
Molding Mercedes-Benz
Mercedes-Benz Notes: UP TO END OF MODEL YEAR 93
FROM MODEL YEAR'91
TO BE PAINTED PRIOR TO INSTALLATION
FROM MODEL YEAR'91
TO BE PAINTED PRIOR TO INSTALLATION
Description: On rear lid.
137
Mounting Rail Mercedes-Benz
Mercedes-Benz Notes: UP TO END OF MODEL YEAR 93
FROM MODEL YEAR'91
FROM MODEL YEAR'91
Description: Ornamental cover to rear lid.
$190.00
$190.00
140
Securing Mercedes-Benz
Mercedes-Benz Notes: UP TO END OF MODEL YEAR 93
FROM MODEL YEAR'91
FROM MODEL YEAR'91
Description: Ornamental cover to rear lid.
$3.00
$3.00
143
Screw Mercedes-Benz
Mercedes-Benz Notes: UP TO END OF MODEL YEAR 93
FROM MODEL YEAR'91
FROM MODEL YEAR'91
Description: Ornamental cover to rear lid.
143
Screw Mercedes-Benz
Mercedes-Benz Notes: UP TO END OF MODEL YEAR 93
FROM MODEL YEAR'91
FROM MODEL YEAR'91
Description: ORNAMENTAL COVER TO REAR LIDDiameter: 5mmStrength / hardness class: 4.8Thread code letter: MThread pitch: 1mm. CONTROL MODULE MOUNTINGDiameter: 5mmStrength / hardness class: 4.8Thread code letter: MThread pitch: 1mm. HEATER PLUG CABLE TO FUSE BOXDiameter: ...
146
Cover Cap Mercedes-Benz
Mercedes-Benz Notes: UP TO END OF MODEL YEAR 93
FROM MODEL YEAR'91
FROM MODEL YEAR'91
Description: Lock to rear lid ornamental cover fixture.
$2.20
$2.20
201
Pan Head Screw Mercedes-Benz
Mercedes-Benz Notes: UP TO END OF MODEL YEAR 93
Description: For license plate. Customs license plate to moulding. Rear license plate.
$8.00
$8.00
No.
Part # / Description / Price
Price
198
Mounting Plate Mercedes-Benz
Mercedes-Benz Notes: FROM MODEL YEAR 94
Description: License plate to rear-end door. Front license plate to rear panel door. License plate to rear lid. License plate mounting. On rear lid.
$82.00
$82.00
